OCL: |
Pin 1-7= 1.45mH Min. @100KHz/1V |
LK: |
Pin 1-7(pendek 8-11.11-14)= 10.5uH Maks 100KHz 1V |
Pin 1-7(pendek 8-14)= 7.2uH Maks 100KHz 1V |
|
Nisbah Pusingan: |
28:6:6 ±3%. @20KHz/1.0V |
DCR: |
1-7: 68mΩ Maks. |
8-14: 8mΩ Maks. |
|
Hi-POT : |
N1-N2: 3750V AC/3mA/ 60S. |
N1-TERAS: 3750V AC/3mA/ 60S. |
|
N2/N3--TERAS: 500V AC/3mA/ 60S. |
|
IR: |
N1-N2: 100MΩ Min DC500V |
TERAS GEJEL: 100MΩ Min DC500V |
